Description
Torpado Zenith X Carbon
The first Torpado Impudent gravel model evolves into the new version: Zenith X. Performance levels are significantly raised thanks to new production technologies. Greater reactivity, a more aerodynamic geometry, the asymmetrical swingarm for a better chain line and fully integrated cables make the Zenith X a top-of-the-range gravel bike.
Torpado Zenith X EQUIPMENT:
SRAM APEX AXS – 1X12
CARBON MONOCOQUE UD FRAME
CARBON MONOCOQUE UD FORK
SRAM NEW APEX AXS 1×12 speed GEARBOX
SRAM APEX AXS 12 speed CONTROLS
BRAKES SRAM APEX Hydraulic 160 mm rotors
DISC ALLOY CENTER TUBELESS READY WHEELS
SRAM 1231 11-44 speed CASSETTE
SRAM APEX WIDE 40T CRANKSET
SADDLE SAN MARCO GROUND
TORPADO ALLOY 31.6 mm STEERER
VITTORIA TERRENO MIX COVERINGS 700×38
SKU 24I3X5N
SRAM RIVAL AXS – 2X12
CARBON MONOCOQUE UD FRAME
CARBON MONOCOQUE UD FORK
SRAM RIVAL AXS 2×12 DERAILLEUR
SRAM RIVAL AXS 12 speed CONTROLS
BRAKES SRAM RIVAL AXS Hydraulic 160 mm rotors
DISC ALLOY CENTER TUBELESS READY WHEELS
CASSETTE SRAM 1250 10-36
SRAM RIVAL AXS 46-33 CRANKSET
SADDLE SAN MARCO GROUND
TORPADO ALLOY 31.6 mm STEERER
VITTORIA TERRENO MIX COVERINGS 700×38
SKU 24I3X6N
SHIMANO GRX 610 – 1X12
CARBON MONOCOQUE UD FRAME
CARBON MONOCOQUE UD FORK
SHIMANO NEW GRX 610 1×12 speed GEARBOX
SHIMANO GRX 610 CONTROLS
BRAKES SHIMANO GRX 610 Hydraulic 160 mm rotors
DISC ALLOY CENTER TUBELESS READY WHEELS
SHIMANO 7100 CASSETTE 10-51
SHIMANO GRX 610 40T CRANKSET
SADDLE SAN MARCO GROUND
TORPADO ALLOY 31.6 mm STEERER
VITTORIA TERRENO MIX COVERINGS 700×38
SKU 24I3X4N
SHIMANO GRX 610 – 2 X 12
CARBON MONOCOQUE UD FRAME
CARBON MONOCOQUE UD FORK
SHIMANO NEW GRX 610 2×12 speed GEARBOX
SHIMANO GRX 610 CONTROLS
BRAKES SHIMANO GRX 610 46-30 Hydraulic 160 mm rotors
Fulcrum Racing 900 WHEELS
SHIMANO 7100 CASSETTE 11-34
SHIMANO GRX 610 46-30 CRANKSET
SADDLE SAN MARCO GROUND
TORPADO ALLOY 31.6 mm STEERER
VITTORIA TERRENO MIX COVERINGS 700×38
SKU 24I3X7N
GEOMETRIES Torpado Zenith X
| SIZE | SEAT TUBE LENGTH (mm) | F TOP TUBE HORIZONTAL (mm) | D HEAD TUBE LENGTH (mm) | AND SEAT TUBE ANGLE EFFECTIVE (°) | C HEAD TUBE ANGLE (°) | FC FRONT CENTRE (mm) | RC CHAIN STAY LENGTH (mm) | WB WHEELBASE (mm) | DROP | STACK (mm) | REACH (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SMALL | 490 | 520 | 120 | 74.5° | 70.5° | 594 | 435 | 1020 | 67 | 537 | 371 |
| MEDIUM | 520 | 535 | 140 | 74th | 71st | 601 | 435 | 1025.4 | 67 | 557 | 375 |
| LARGE | 540 | 550 | 150 | 73rd | 71.5° | 601 | 435 | 1024.9 | 67 | 568 | 376 |
| X-LARGE | 560 | 565 | 170 | 73rd | 72nd | 611 | 435 | 1035.5 | 67 | 590 | 385 |
| XX-LARGE | 590 | 590 | 190 | 73rd | 72nd | 635.4 | 435 | 1061 | 67 | 611.9 | 379 |
*The manufacturer reserves the right to make all the changes, technical improvements and cancellations of discontinued items to the products that are deemed appropriate, at any time and without notice. The descriptions and dimensions given in this publication are therefore not binding.
